- Number of Spools: 1-6
- Spool Diameter: 20mm
- Nominal Flow: 90 LPM
- Maximum Pressure on P, A & B Ports. Bar (psi): 350 (5075)
- Maximum Pressure on T Port. Bar (psi): 50 (725)
- Inlet Relief Valve Adjustment Range. Bar (psi): 10-300 (145 – 4350)
- Hydraulic Fluid: Mineral Oil to DIN 51524
- Viscosity Range: 12-400 cSt
- Fluid Temperature Range: -20°C to 80°C
- Maximum Contamination Level:
o ISO 4406 – Class 19/16
o NAS 1638 – Class 10 - Ambient Temperature Range: -40°C to 60°C
